HOT ROLLED PLATES
High quality, industrial grades plates for pressure vessels, structural steel, tool for various industries such as Shipbuilding, industrial tools and machinery and Oil & Gas.
NLMK Europe offer Hot rolled plates weighting up to 50 tons with thickness ranging from 3 to 360mm, Length up to 24m and Width up to 4050mm. Q Steel FZE represents three plate mills of NLMK Europe.
Belgium:
NLMK Clabecq manufactures Thin & Light plates, with thickness ranging from 3mm to 120mm. Following plates are manufactured, at their latest facilities:
- Plain / Checkered / Teardrop plates (Floor plates)
- Quard plates
- Quend plates
Denmark:
NLMK DanSteel manufactures Wide & Large plates, with thickness ranging from 5mm to 200mm and width ranging from 1000mm to 4050mm. The new normalizing units can cater to heat treatment of up to 70% of its production.
Italy:
NLMK Verona specialises in the production of Thick & Heavy forging ingots, forged and rolled plates, with thicknesses ranging from 20mm to 1500mm. It has launched new grades in the boiler and tool steel categories
The NLMK plates are used for the following industries and applications:
- Structural steel for fabrication
- Checkered/Tear drop plates (Floor plates)
- Corrosion resistant plates (Corten plates)
- Plates for Shipbuilding and Offshore industries
- Plates for Boilers, pressure vessels and oil & gas storage tanks
- Alloy steel, High carbon steels
- Line pipe steels- Sour Service & Non Sour Service
- Tool Steels – Engineering steels
- Construction of wind generators and other energy installations
- Construction of earthmoving, mining, quarry and defence equipments
- Construction of pipelines for gas, oil and water
- High yield strength steels
- Extra high tensile strength steel – Quend
- Wear/Abrasion resistant plates – Quard
Steel grades and their Application
| Application / Steel Category | Grades |
|---|---|
| Structural Steels |
S235/S275/S355/S460/S690 ASTM A36/A283/A572/A573/A633 |
| Corten steels | 355JOW/JOWP/J2W/J2WP |
| Offshore |
API 2H – 50, API 2W – 50,
S355G2 + N, S355G3 + N, S355G7-G10+N/M S420-S460+N/M S690QL |
| Pressure vessels |
P275/355/460 N/NH/NL1/NL2
P355/420/460 M/ML1/ML2 P400 NGJ4 16Mo3 DIN17155:1983 HI, DIN17155:1983 HII BS1501:1980 151-430A up to 225-490B A516 Gr. 55, 60, 65, 70 with improved properties after PWHT A516 Gr. 60 – 70 HIC (sour service) A612 (higher resistance) A387 Gr. 11 Cl.2/ Gr. 12 Cl.2/Gr. 22 A537 Class 1(N) and Class 2 (Q&T) |
| Plates for pipes |
From X52M/L360M to X80M/L555M From X52MS/L360MS to X80MS/L555MS |
| Tool steels |
1.2311/1.2312, 1.2316
1.2714/1.2738 1.2085 , 1.2083, 1.2343, 1.2344, 1.2367, 1.2363, 1.2842, 1.2510 VR400 C45/C55/C60/1.1730 |
| Shipbuilding | AH36, DH36, EH36 |
| Alloy Steels |
4130/4140
16MnCr5/20 MnCr5 41Cr4 |
| Wind mills |
S355 J2+N or NL
S355NL CAC (EN10025-3) S355K2 ACC + N (EN10025-2) S420/460 N/NL S420/460 M/ML |
